Description
Product brand: DELTA
Dimensions: 92 x 92 x 25mm
Rated voltage: DC12V
Voltage range: DC7.0V-13.6V
Input power: 0.40 A
Speed: 3150 r.p.m
Temperature range: -10.. 70 C
Life expectancy: 25 degrees L10, C is expected to live 35000 hours
Bearing structure: maintenance free double ball bearing
Rotating direction: the wind is discharged from the bracket, and the face of the rotor is rotated counter clockwise.
Wiring: + yellow – Black speed green PWM: blue
Maximum wind quantity: 98.4 m3/h
Motor protection: fault level protection and protection of the lock and the lock flow
Minimum wind pressure: 55.. 0 Pa
Noise: 38 dB (A)
Material: glass fiber reinforced plastic, PBT shell, PA blade
