Note: For the nozzles, 0.2/0.3/0.4/0.5mm are for option. If you need other sizes besides the 0.4mm, please leave us a note.
Item details
Nozzle Size：0.4mm for 1.75mm Fliament.
( If you need 0.2/0.3/0.5 Nozzle size , please tell us before the order)
Thermistor： 100K, NTC 3950, 1 meter
Heater wire：12V or 24V, 40W, 1meter.
Teflon tube：1 meter ,Bore ID4mm OD6mm ,white.
Cooling Fan：30*30*10mm ,12V or 24V ,2 Pin ,with Bracket.
V6 Heating Block:
Size: 20mm*16mm*11.5mm Material: 6061 aluminium alloy The screw with gasket suited: M3 * 10 and M3 * 4
V6 Throat Tube: Specifications: inner hole 2mm; radiating end threaded M7; heated end M6; total length : 22.4mm Material: 316F / stainless steel Scope: 3D-V6 long distance wire; Features: Tail part: 4.2mm hole, wearing Φ4 × 2 Teflon tube, reducing friction with the wire during the heat pipe wall.
V6 Heat Cooling Tube: Specifications: connection thread M7 Joint connecting thread G1/8 Feeding hole Φ4.2 (with 4 × 2 Teflon tube PTFE) Installation position Φ12 × 3.7
V6 Nozzle: Dimensions: 12.5mm * 7mm Material: Copper Nozzle Accuracy: 0.2mm, 0.3mm, 0.4mm, 0.5mm (support 1.75mm) Screw outer diameter: 6mm (Metric M6, tooth length 5.5mm, ID 2mm) Machining error is within 0.005mm. Customization is available.
V6 Pneumatic Fittings:
Inner diameter: 4mm for 1.75mm filament guiding tube – ID2mm OD4mm PTFE tube use
Thread: 1/8″
Package list:
1. V6 remote hotend kit * 1
2. Cooling fan with Bracket * 1
3. 1 meter Teflon tube * 1
4. 1 meter thermistor&heater wire * 1
