Sale!

Free Shipping Quality Product Industrial Electric Cabinet Heater 300w Space-saving Heater Without Fan

$42.30 $38.49

7 in stock

SKU: 32329933594 Category:

Description

Product Feature :

1. HV031 heater 100W -400w

2. Have the CE.ROSH

3. Compact

4. Flat design

5. High air through-flow

6. Temperature safety cut-out

7. Clip fixing

The compact high-performance fan heater prevents formation of

condensation in control or switch systems and provides an evenly

distributed interior air temperature in enclosures. This fan heater

is available with fan (HVL 031) as well as without fan (HV031).

Important : Heater may only be operated together with fan.

Danger of overheating!

Technical Datas :

HV 031 Heater without fan (fan mounting kit included)
HVL 031 Heater with fan
Heating element high performance cartridge
Temperature safety cut-out to protect against overheating in case of fan failure
Heater body die-cast aluminium (glass bead blasted)
Connection 3-pole screw connector 2.5mm2,clamping torque 0.8Nm max.
Connection casing plastic according to UL94 V-0, black
Mounting clip for 35mm DIN rail, EN 50022
Fitting position horizontal
Operating / Storage temperature -45 to +70°C (-49 to +158°F)
Protection type / Protection calss IP20 / I (earthed)
Connection (axial fan) 2-pole screw connector 2.5mm2(L2/N2)
HVL 031 only:
Axial fan, ball bearing airflow see table
service life 50,000h at 25°C (77°F)

Note : all the heater voltage has 120VAC and 230VAC ,

when you place the order , pls note the voltage ,

and leave message about the voltage to us .

Or we just send you 230VAC . Thanks .




Similar Product


Additional information

Item Type

Switches

Brand Name

JoHigh

Certification

CE

Switch Type

Temperature Switch

Model Number

HV031-300w

Warranty

1year

Type

Industrial Heater

Heater body

die-cast aluminium (glass bead blasted)

Mounting

clip for 35mm DIN rail EN 60715

Power

300W

Operating/Storage temperature

-45 to +70°C (-49 to +158°F)

Fitting position

horizontal

Heater element

high performance cartridge

Protection class

IP20 / I (earthed)
