Descrizione
【Tipo di ventola】 DC axial fan
【Dimensioni della ventola】 120 × 120 × 38 mm
【Fan Model】 MGA12024XR-O38
[Intervallo di tensione] DC 14.0V ~ 27.6V
【Tensione nominale】 CC 24 V
[Nominal current] 0.34UN
【Corrente nominale】 0.34UN
【Potenza di ingresso】 8.16W
[Velocità nominale] 2400 giri al minuto
[Volume d'aria] 112.40 CFM (piedi cubi al minuto) = 3.183 CMM (metri cubi / minuto)
【Pressione del vento】 5.61 mmAq (mm di colonna d'acqua) = 0.221 inchAq (inches of water column)
[Rumore] 41.4 dB-A (sub-chanting)
【Product net weight】 300 G
[Lead terminal] standard 2 pin positive and negative lead wire, no terminal plug, line length of about 30cm. Need to specify the specified plug, please contact customer service
[Function support] (O) Automatic restart and lock current protection
【Protection function】 stall protection, reverse protection
[Motor bearing type] Doppio cuscinetto a sfere
【Frame and fan material】 plastic material
[Use of the environment and life] minus -10 ° to zero on the 70 °, the normal environment sustainable operation about 50,000 ore
