Beschreibung
Voltage rated 24VDC
Größe / scale square – 92mm x 92mm x 38.4mm long high width
The airflow of 152.5 CFM (4.32m3 / min)
Static pressure of 1.200 Zoll Wasser (298.9 Pa)
The type of bearing ball
Fan type pipe shaft type
Eigenschaften –
Noise of 62.5 dB (EIN)
Leistung (W) 27.1W
RPM 7200 RPM
Terminal 2 führen
The weight of 0.507 Pfund (229.97G)
Arbeitstemperatur 14 ~ 158 degrees F (-10 ~ 70 C)
Rated current 1.13A
Spannungsbereich 14 ~ 26.4VDC
Life expectancy at 25 C for 100000 Std
